故障參考地址系列90-30/90-20/MicroPLC中的故障參考地址只有一類:故障累積(summary)參考地址。將故障累加參考地址登記,以表明何種故障已發(fā)生。故障地址將一直維持導通,直到PLC被清屏或直到應用程序清屏。下面是一個故障位先置后清的例子。在該例中,當掃描超限狀態(tài)發(fā)生時,線圈Light-01(燈-01)接通,燈和OV-SWP觸點將維持通,直到%10359觸點閉合為止。
